| Light Duty Rack | |
| Enlarge The Picture |
| Warehouse Rack---Light Duty Rack |
|
|
|
| Light Duty Rack | |
| Enlarge The Picture |
| =specifications= |
| Light Duty Rack is a structure system of good universality with the pleasing shape meanwhile assemble freely..The beam can adjust the layer height as per 50mm.on condition of heavy carrying capacity as well as with the long beam. In general, it is available to bear the weight of 150-300kg and the shelf surface can be equipped with the steel plate and wood plate( including the log plate, medium density fibreboard and flakeboard) |
| (standard specification) |
| Size L×D（mm） | 1500×500 | 1500×600 | 1500×700 | 1800×500 | 1800×600 | 1800×700 | 2000×500 | 2000×600 | 2000×700 |
| Loading Capacity per Layer (Kg) | 350 | 350 | 350 | 300 | 300 | 300 | 250 | 250 | 250 |
| Size of Upright | 55×47×1.8mm (Adjust distance=50mm)H=1800mm，2000mm,2400mm | ||||||||
| Surface treatment | Powder Coating | ||||||||
| =Other Pictures= |
|
|
|
 |
|
|
|
 |
 |
 |
|
|
|
